- Description
- AX5700 Dual Band WiFi 6 Gaming Router, PS5 compatible, Mobile Game Mode, Lifetime Free Internet Security, Mesh WiFi support, 2.5G Port*, Gaming Port, Adaptive QoS, Port Forwarding
- Brand
- ASUS
- Model
- RT-AX86U
- Dimensions
- 9.53″ x 3.94″ x 12.80″ (WxDxH) with antenna 9.53″ x 3.94″ x 6.46″ (WxDxH) without antenna
- Weight
- 1.80 lbs.
- AC Input
- 110V~240V (50~60Hz)
- Access Control
- Parental control, Network service filter, URL filter, Port filter
- Antenna
- 3 x External antenna 1 x Internal PCB antenna
- ASUS AiMesh Support
- Create a flexible, seamless whole-home mesh network with AiMesh-compatible routers
- Buttons
- WPS Button, Reset Button, Power Switch, LED on/off Button
- DC Output
- 19 V with max. 2.37 A current
- Device Management
- UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log
- Firewall
- SPI intrusion detection, DoS protection
- Frequency Band
- 2.4 GHz / 5 GHz
- Guest Network
- 2.4 GHz x 3, 5 GHz x 3
- Interface
- 2 x USB 3.2 Gen 1
- LAN Ports
- 4 x 10/100/1000M
- LEDs
- 1 x Power 2 x Wi-Fi 1 x 2.5G Port 1 x WAN 4 x LAN 1 x WPS
- Mobile Game Mode
- Minimize lag and latency for mobile gaming with just a tap on the ASUS Router app
- Operating Range
- Very large homes
- Operation Mode
- Access Point Mode / Media Bridge Mode / Wireless Router Mode
- Package Contents
- RT-AX86U WiFi router RJ-45 cable Power adapter Quick Start Guide Warranty card
- Power Adapter
- AC Input: 110V~240V (50~60Hz) DC Output: 19 V with max. 2.37 A current
- Processor
- 1.8 GHz quad-core processor
- Security
- Firewall: SPI intrusion detection, DoS protection Access control: Parental control, Network service filter, URL filter, Port filter
- Standards
- IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6
- True 2 Gbps Wired And Wireless Speeds
- Aggregated 2 Gbps WAN connections, wired 2.5 Gbps port* and WiFi 6
- VPN Client
- PPTP client, L2TP client, OpenVPN client
- VPN Server
- PPTP Server, OpenVPN Server, IPSec server
- VPN Support
- IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through IPSec server PPTP server OpenVPN server PPTP client L2TP client OpenVPN client
- WAN Ports
- 1 x 10/100/1000M; 1 x 2.5G
- Wireless Data Rates
- 802.11a : 6,9,12,18,24,36,48,54 Mbps 802.11b : 1, 2, 5.5, 11 Mbps 802.11g : 6,9,12,18,24,36,48,54 Mbps 802.11n : up to 450 Mbps 802.11n (1024 QAM) : up to 750 Mbps 802.11ac (1024 QAM) : up to 4333 Mbps 802.11ax (2.4GHz) : up to 861 Mbps 802.11ax (5GHz) : up to 4804 Mbps
- Wireless Standard
- IEEE 802.11a / IEEE 802.11ac / IEEE 802.11ax / IEEE 802.11b / IEEE 802.11g / IEEE 802.11n
- WPA
- WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
