- Description
- Gigabit WiFi for 8K Streaming - 5400 Mbps WiFi for faster browsing, streamings, and downloading, all at the same time. †
- Dimensions (W×D×H)
- 10.7 × 5.8 × 1.9 in (272.5 × 147.2 × 49.2 mm)
- USB Sharing
- 1× USB 3.0 port enables easy media sharing and private cloud building.
- USB Support
- 1× USB 3.0 Port Supported Partition Formats: NTFS, exFAT, HFS+, FAT32 Supported Functions: Apple Time Machine FTP Server Media Server Samba Server
- Buttons
- Wi-Fi On/Off Button Power On/Off Button LED On/Off Button WPS Button Reset Button
- Certifications
- FCC, CE, RoHS
- Cloud Service
- Auto Firmware Upgrade TP-Link ID DDNS
- DDNS
- TP-Link NO-IP DynDNS
- DHCP
- Address Reservation DHCP Client List Server
- Easy Setup
- Set up the router in minutes with Tether app.
- Environment
- Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
- Ethernet Ports
- 1× Gigabit WAN Port 4× Gigabit LAN Ports Static Link Aggregation (LAG) available with 2× LAN ports
- Extensive Coverage
- 6× antennas and Beamforming ensure broad coverage.
- Gigabit WiFi For 8K Streaming
- 5400 Mbps WiFi for faster browsing, streamings, and downloading, all at the same time. †
- Guest Network
- 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network
- HomeShield
- TP-Link's premium security services keep your home network safe with cutting-edge features for network and IoT protection.*
- IPTV
- IGMP Proxy IGMP Snooping Bridge Tag VLAN
- Management Features
- Tether App Webpage
- NAT Forwarding
- Port Forwarding Port Triggering DMZ UPnP Virtual Server
- Network Security
- SPI Firewall Access Control IP & MAC Binding Application Layer Gateway HomeShield Security Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner
- Network Services Enabled By Default
- Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP DNS DNS • Port: 53 Protocol: TCP & UDP DHCP Server IP address assignment (DHCP) • Port: 67 Protocol: UDP App management Manage and configure device through app • Port: 20001 Protocol: TCP • Port: 30001 Protocol: TCP • Port: 20002 Protocol: UDP
- OneMesh™
- OneMesh™ Supported Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products. Learn More> All OneMesh Products>
- Operating Humidity
- 10%~90% non-condensing
- Operating Temperature
- 0℃~40℃ (32℉ ~104℉)
- Package Content
- Wi-Fi Router Archer AX73 Power Adapter RJ45 Ethernet Cable Quick Installation Guide
- Parental Controls
- HomeShield Parental Controls Custom Profiles Professional Content Filter Library Family Time Bedtime Off Time Time Rewards Family Online Time Ranking Pause the Internet Weekly and Monthly Reports
- Power
- 12 V ⎓ 2.5 A
- Processor
- 1.5 GHz Triple-Core CPU
- Protocols
- IPv4 IPv6
- Quality Of Service
- QoS by Device
- Service Kits
- HomeShield Learn More>
- Standards And Protocols
- Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz
- Storage Humidity
- 5%~90% non-condensing
- Storage Temperature
- -40℃~70℃ (-40℉ ~158℉)
- System Requirements
- Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access)
- VPN Client
- • Open VPN Client • PPTP VPN Client • L2TP VPN Client
- VPN Server
- OpenVPN PPTP
- WAN Types
- Dynamic IP Static IP PPPoE PPTP L2TP
- Warranty
- 1 Year
- WiFi Capacity
- High Dual-Band Allocate devices to different bands for optimal performance 4×4 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple Wi-Fi 6 clients Airtime Fairness Improves network efficiency by limiting excessive occupation DFS Access an extra band to reduce congestion 6 Streams Connect your devices to more bandwidth
- WiFi Encryption
- WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x)
- WiFi Range
- 3 Bedroom Houses 6× Fixed High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage 4T4R Multiple streams in the same band strengthen the fault tolerance in transmission
- WiFi Speeds
- AX5400 5 GHz: 4804 Mbps (802.11ax, HE160) 2.4 GHz: 574 Mbps (802.11ax)
- WiFi Transmission Power
- CE: <20dBm{2.4GHz} <23dBm{5.15GHz~5.35GHz} <30dBm{5.47GHz~5.725GHz} FCC: <24dBm{5.25GHz~5.35GHz&5.47GHz~5.725GHz } <30dBm{2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz }
- Working Modes
- Router Mode Access Point Mode
