- Description
- Customizable screen size with All-in-One design for hassle-free installation
- Color Temperature
- 3000K - 10000K
- Weight
- 5 kg (11.023 lbs)
- USB Type A
- 3 (USB 3.0 ×1, USB 2.0 ×2)
- USB Type A (Power)
- Shared (multiple outputs)
- USB Type A (Service)
- 1
- USB Type C
- 1 (Data only)
- USB Type C (Power)
- Shared (5V/1A)
- Audio Out
- 2 (3.5mm)
- Bonding Wire
- Copper
- Brightness
- 600 nits (100 levels adjustable)
- Contrast Ratio
- 6500:01:00
- Embedded OS
- Android 9.0
- HDMI Input
- 4 (HDMI 2.0 / HDCP 2.2)
- HDMI Output
- 1 (HDMI 1.4 / HDCP 1.4)
- HDTV Compatibility
- 480p, 576p, 720p, 1080p, 2160p
- Horizontal Frequency
- 31K-94KHz
- Impact Rating
- IK06 (Front)
- IP Rating
- IP54 (Front)
- IR In
- 1 (3.5mm)
- IR Receiver
- 1
- LED Cabinets With A Native 16
- 9 aspect ratio for easy configuration of 4K and FHD resolutions
- LED Lifetime
- 100,000 hours
- LED Modules
- 4 per cabinet
- LED Package Type
- SMD 3-in-1 (GOB)
- Light Sensor
- 1
- Local Storage
- 32GB (26GB usable)
- Maintenance Tools
- LD-MK-004, LD-MK-006
- Operating Temperature
- 0-40°C
- Optional Control Box
- LD-SCB-011, LD-SCB-021
- Optional Floor Stand
- LD-STND-009
- Orientation
- Landscape
- Panel Technology
- Direct View LED
- Pixel Pitch
- 1.875 mm
- Power Consumption (m²)
- 114W (typ), 341W (max)
- Power Consumption (Unit)
- 23W (typ), 69W (max), <0.5W (hibernate)
- Power Supply
- 100-240V ~ 50/60Hz
- Resolution Support
- VGA (640×480) to 4K (3840×2160 @60Hz)
- RJ45 (LAN Control)
- 1
- RJ45 Input
- 3 (Internet ×2, Control ×1)
- RS232
- 1
- S/PDIF
- 1
- Screen Size
- 27″
- Spare Parts
- LED Module (7%), Hub Board
- Speakers
- 30W ×2
- Standard Accessories
- Control Box, Power Cord, LAN Cable, IR Extender, Remote, Wall Mount
- Vertical Scan Rate
- 56-85Hz
- Viewing Angles
- H: 170°, V: 170°
- Wi Fi
- 2.4G / 5G Hz
