- Description
- Google certified EDLA with access to Google apps on Android™ 16
- Colors
- 1.07B (8-bit + FRC)
- RAM
- 8 GB
- USB Type A
- 4 (Front x2 USB 3.2 Gen1 Smart USB, Side x1 USB 3.2 Gen1 EDLA, Side x1 USB 2.0 Smart USB)
- USB Type B
- 2 (Front x1 USB 2.0, Side x1 USB 2.0)
- USB Type C
- 1 (Front USB 3.2 Gen1, PD, extended screen & touchback not supported)
- Audio In
- 1
- Audio Out
- 1
- Aspect Ratio
- 16:09
- Backlight Life
- 50,000 Hours
- Bezel Size
- 16.55 × 16.55 × 16.55 × 45 mm (L/R/T/B)
- Brightness
- 400 nits
- Consumption
- On: 72.54W (Normal), Off: <0.5W
- Contrast Ratio
- 5000:1 (Max with DCR enabled)
- Display Area
- 1428.48 × 803.52 mm (64.5”)
- Embedded OS
- Android 16 (EDLA)
- Environmental Sensor
- Yes
- Gross Weight
- 38.2 kg (84.22 lb)
- HDMI
- 3 (Front:1, Rear:2; HDMI 2.0, 4K@60Hz, HDCP1.4/2.2, CEC, Rear HDMI supports ARC)
- HDMI Out
- 1 (3840 × 2160 @ 60Hz)
- Humidity
- 20% - 80% RH (non-condensing)
- Light Sensor
- Yes
- Net Weight
- 30.2 kg (66.58 lb)
- On
- 72.54W (Normal), Off: Wall Mount
- OPS Slot
- 1 (80-pin)
- Orientation
- Landscape
- Packaging Size
- 1628 × 1014 × 185 mm (64 × 40 × 7 in)
- Panel Size
- 86″
- Panel Type
- TFT LCD Module with DLED Backlight
- Physical Size
- 1491 × 898.5 × 99.1 mm (58.7 × 35.37 × 3.9 in)
- Processor
- Octa-Core
- Resolution
- UHD 3840 × 2160 Pixels
- Response Time
- 6.5 ms
- RJ45
- 1 (10/100/1000 Mbps, Android max 1000M, OPS & Touch max 100M)
- RS232
- 1
- Screen Resolution
- 2160p (UHD, 4K)
- Screen Size
- 86 Inch
- SPDIF
- 1
- Speakers
- 20W × 2
- Storage
- 128 GB
- Surface Treatment
- 9H Hardness, Anti-glare, Zero bonding
- Technology
- IR Recognition / Ultra Fine Touch
- Temperature
- 0°C - 40°C
- Touch Points
- Windows: 50, Android: 50
- Touch Resolution
- 32768 × 32768
- Viewing Angles
- H=178°, V=178°
- Voltage
- 100-240V AC ±10%
- Wall Mount
- VESA 600 × 400 mm
- WiFi
- Built-in
- Windows
- 50, Android: 50
